Base Permeability Tube VBP
1.1 General information
The equipment consists of a specimen tube with two base permeability screens. Each screen is specially manufactured having fine mesh at one side and course at the other side.
1.2 General Usage
To determine the base permeability of raw sand. Base permeability is the permeability of packed dry sand containing clay, moisture or other bonding substances.
1.3 Product Data
Product Name:
Base Permeability Tube
Product Code:
VBP
Order Reference Code:
V0000029
Electrical Supply Required:
Not Required
Electrical Plug:
Not Applicable
Typical Maximum Current:
Not Applicable
Compressed air Supply:
Not Required (Required for base equipment VPD I)
Communication:
Not Applicable
Dimensions:
70x70x125mm (WXBXH)
Packing Dimensions:
100x100x170mm (WXBXH) Typical
Net Weight:
Approximately 0.9 kg
Gross Weight:
Approximately 1.2 kg
Colour:
Factory Default
Measuring Range:
Not Applicable
Traceable to:
Manufacturers Standards
Least Count:
Not Applicable
Specimen Requirements:
Not Required
Operating Temperature:
0-50 degree Celsius
Testing Standards:
BIS: Standard
AFS: Optional
Calibration Frequency:
1250 nos. of Testing Cycles or Once in Year
2.1 Scope of supply
- Base permeability tube.
- Mesh cup – 02 Nos.
- Instruction manual.
3.1 Recommended pre-requisite equipment
Digital Permeability Meter VPD I or
Digital Permeability Meter VPD II or
Digital Permeability Meter VPD or
Permeability Meter VP
Specimen preparation equipment to make a standard AFS or Metric Compression specimen.
4.1 Recommended Calibration kits
NA
4.2 Recommended attachments
NA
4.3 Alternative equipment
NA
5.1 Consumables
Assy. Mesh cup 50mm VBP (Part # V4500342)
