Description
1.1 General information
The equipment consists of hopper, split core box, base plate, scrapper and plunger with clamping arrangement.
1.2 General Usage
This equipment used for prepare the tensile type specimen of No-bake and CO2 sand.
1.3 Product Data
|
Product Name: |
Tensile Core Box |
|
Product Code: |
VCB |
|
Order Reference Code: |
V0000018 |
|
Electrical Supply Required: |
Not Required |
|
Electrical Plug: |
Not Applicable |
|
Typical Maximum Current: |
Not applicable |
|
Compressed air Supply: |
Not Required
|
|
Communication: |
Not Applicable |
|
Dimensions: |
152x95x65mm (WXBXH) |
|
Packing Dimensions: |
230x230x130mm (WXBXH) Typical |
|
Net Weight: |
Approximately 1.5 kg |
|
Gross Weight: |
Approximately 2.5 kg |
|
Colour: |
Factory Default |
|
Measuring Range: |
Not Applicable |
|
Traceable to: |
Manufacturers Standards |
|
Least Count: |
Not Applicable |
|
Specimen Requirements: |
Not Required
|
|
Operating Temperature: |
0-50 degrees Celsius |
|
Testing Standards: |
BIS: Standard AFS: Optional |
|
Calibration Frequency: |
4500 nos. of Testing Cycles or Once in Year |
2.1 Scope of supply
- Tensile core box.
- Scrapper, Plunger with c clamp.
- Instruction manual.
3.1 Recommended pre-requisite equipment
Sand Rammer VR
CO2 Gassing Acc. Tensile VOCC
4.1 Recommended Calibration kits
NA
4.2 Recommended attachments
NA
4.3 Alternative equipment
Gang Tensile Core Box VGT
5.1 Consumables
NA
